Quickstart: your first sandbox payment

Getting startedTutorial · about 10 minutes

Yuno is the AI operating system for payments, and a payment is the first thing you run on it. You send your first sandbox payment in about 10 minutes once you have sandbox credentials.

Create a connectionSend one payment with a test cardSee it in the dashboard

Get your sandbox credentials

Account code, shown as account_id in the dashboard
public-api-key
private-secret-key

Sandbox keys start with sandbox_. Production keys are different and start with prod_.

If you do not have an account yet, ask your Yuno contact or write to sales@y.uno. There is no self-serve signup today.

Connect the Yuno Test Payment Gateway and publish a route

The Yuno Test Payment Gateway simulates a card provider. It works in sandbox only and needs no credentials.

Open Connections, search for Yuno Test Payment Gateway, click Connect, name the connection, and click Save.
Open Routing, open the Not published tab, find Card, and click Set Up.
Click + Create new route, name it, and click Save.
Click the arrow, choose Add step, select Yuno Test Payment Gateway, and click Publish.
Open Checkout builder, turn on Card, and publish the settings.

Send the payment

API
Web SDK

Sending raw card numbers from your server is for sandbox testing. In production it requires PCI DSS scope. Otherwise use the Yuno SDK or Secure Fields to collect card data.

The API tab uses the DIRECT workflow, a back-to-back payment where your server sends the card data. Set your credentials as environment variables:

Shell

export YUNO_PUBLIC_API_KEY="sandbox_..."
export YUNO_PRIVATE_SECRET_KEY="sandbox_..."
export YUNO_ACCOUNT_ID="your-account-code"

First, create a customer. The base URL is https://api-sandbox.y.uno.

curl --request POST \
  --url https://api-sandbox.y.uno/v1/customers \
  --header "public-api-key: $YUNO_PUBLIC_API_KEY" \
  --header "private-secret-key: $YUNO_PRIVATE_SECRET_KEY" \
  --header "content-type: application/json" \
  --data '{
    "merchant_customer_id": "customer-0001",
    "first_name": "John",
    "last_name": "Doe",
    "email": "john.doe@example.com"
  }'

const res = await fetch("https://api-sandbox.y.uno/v1/customers", {
  method: "POST",
  headers: {
    "public-api-key": process.env.YUNO_PUBLIC_API_KEY,
    "private-secret-key": process.env.YUNO_PRIVATE_SECRET_KEY,
    "content-type": "application/json",
  },
  body: JSON.stringify({
    merchant_customer_id: "customer-0001",
    first_name: "John",
    last_name: "Doe",
    email: "john.doe@example.com",
  }),
});
const customer = await res.json();
console.log(customer.id);

import os
import requests

res = requests.post(
    "https://api-sandbox.y.uno/v1/customers",
    headers={
        "public-api-key": os.environ["YUNO_PUBLIC_API_KEY"],
        "private-secret-key": os.environ["YUNO_PRIVATE_SECRET_KEY"],
    },
    json={
        "merchant_customer_id": "customer-0001",
        "first_name": "John",
        "last_name": "Doe",
        "email": "john.doe@example.com",
    },
)
print(res.json()["id"])

The response includes an id. Save it as YUNO_CUSTOMER_ID for the next call.Then create the payment with a test card. Send a new X-Idempotency-Key with each payment.

curl --request POST \
  --url https://api-sandbox.y.uno/v1/payments \
  --header "public-api-key: $YUNO_PUBLIC_API_KEY" \
  --header "private-secret-key: $YUNO_PRIVATE_SECRET_KEY" \
  --header "X-Idempotency-Key: $(uuidgen)" \
  --header "content-type: application/json" \
  --data '{
    "account_id": "'"$YUNO_ACCOUNT_ID"'",
    "merchant_order_id": "order-0001",
    "description": "First test payment",
    "country": "US",
    "amount": { "currency": "USD", "value": 25 },
    "workflow": "DIRECT",
    "customer_payer": { "id": "'"$YUNO_CUSTOMER_ID"'" },
    "payment_method": {
      "type": "CARD",
      "detail": { "card": { "card_data": {
        "number": "4507990000000002",
        "expiration_month": 11,
        "expiration_year": 28,
        "security_code": "123",
        "holder_name": "John Doe"
      } } }
    }
  }'

const res = await fetch("https://api-sandbox.y.uno/v1/payments", {
  method: "POST",
  headers: {
    "public-api-key": process.env.YUNO_PUBLIC_API_KEY,
    "private-secret-key": process.env.YUNO_PRIVATE_SECRET_KEY,
    "X-Idempotency-Key": crypto.randomUUID(),
    "content-type": "application/json",
  },
  body: JSON.stringify({
    account_id: process.env.YUNO_ACCOUNT_ID,
    merchant_order_id: "order-0001",
    description: "First test payment",
    country: "US",
    amount: { currency: "USD", value: 25 },
    workflow: "DIRECT",
    customer_payer: { id: process.env.YUNO_CUSTOMER_ID },
    payment_method: {
      type: "CARD",
      detail: { card: { card_data: {
        number: "4507990000000002",
        expiration_month: 11,
        expiration_year: 28,
        security_code: "123",
        holder_name: "John Doe",
      } } },
    },
  }),
});
const payment = await res.json();
console.log(payment.status, payment.sub_status);

import os
import uuid
import requests

res = requests.post(
    "https://api-sandbox.y.uno/v1/payments",
    headers={
        "public-api-key": os.environ["YUNO_PUBLIC_API_KEY"],
        "private-secret-key": os.environ["YUNO_PRIVATE_SECRET_KEY"],
        "X-Idempotency-Key": str(uuid.uuid4()),
    },
    json={
        "account_id": os.environ["YUNO_ACCOUNT_ID"],
        "merchant_order_id": "order-0001",
        "description": "First test payment",
        "country": "US",
        "amount": {"currency": "USD", "value": 25},
        "workflow": "DIRECT",
        "customer_payer": {"id": os.environ["YUNO_CUSTOMER_ID"]},
        "payment_method": {
            "type": "CARD",
            "detail": {"card": {"card_data": {
                "number": "4507990000000002",
                "expiration_month": 11,
                "expiration_year": 28,
                "security_code": "123",
                "holder_name": "John Doe",
            }}},
        },
    },
)
payment = res.json()
print(payment["status"], payment["sub_status"])

The payment succeeds when the response looks like this:

Response (trimmed)

{
  "id": "6c44ed29-cc51-4479-a5eb-108afdaadd50",
  "status": "SUCCEEDED",
  "sub_status": "APPROVED",
  "amount": { "currency": "USD", "value": 25 }
}

The Web SDK tab splits the work. Your server creates a checkout session, and the browser loads the SDK and starts the transaction.On your server, create the checkout session. Use workflow: "SDK_SEAMLESS" so the SDK creates the payment for you. Without it the transaction ends in INTERNAL_ERROR.

curl --request POST \
  --url https://api-sandbox.y.uno/v1/checkout/sessions \
  --header "public-api-key: $YUNO_PUBLIC_API_KEY" \
  --header "private-secret-key: $YUNO_PRIVATE_SECRET_KEY" \
  --header "content-type: application/json" \
  --data '{
    "account_id": "'"$YUNO_ACCOUNT_ID"'",
    "merchant_order_id": "order-0001",
    "payment_description": "First test payment",
    "country": "US",
    "amount": { "currency": "USD", "value": 25 },
    "workflow": "SDK_SEAMLESS"
  }'

const res = await fetch("https://api-sandbox.y.uno/v1/checkout/sessions", {
  method: "POST",
  headers: {
    "public-api-key": process.env.YUNO_PUBLIC_API_KEY,
    "private-secret-key": process.env.YUNO_PRIVATE_SECRET_KEY,
    "content-type": "application/json",
  },
  body: JSON.stringify({
    account_id: process.env.YUNO_ACCOUNT_ID,
    merchant_order_id: "order-0001",
    payment_description: "First test payment",
    country: "US",
    amount: { currency: "USD", value: 25 },
    workflow: "SDK_SEAMLESS",
  }),
});
const session = await res.json();
console.log(session.checkout_session);

import os
import requests

res = requests.post(
    "https://api-sandbox.y.uno/v1/checkout/sessions",
    headers={
        "public-api-key": os.environ["YUNO_PUBLIC_API_KEY"],
        "private-secret-key": os.environ["YUNO_PRIVATE_SECRET_KEY"],
    },
    json={
        "account_id": os.environ["YUNO_ACCOUNT_ID"],
        "merchant_order_id": "order-0001",
        "payment_description": "First test payment",
        "country": "US",
        "amount": {"currency": "USD", "value": 25},
        "workflow": "SDK_SEAMLESS",
    },
)
print(res.json()["checkout_session"])

In the browser, load the SDK from the CDN, then start a transaction with the checkout_session value from your server.

Browser

<div id="payment-form"></div>
<script src="https://sdk-web.y.uno/v2.0.0/main.js"></script>
<script>
  async function startYuno() {
    const sdkPayments = await SdkPayments.initialize("your-public-api-key");
    const transaction = sdkPayments.transaction({
      checkoutSession: "checkout-session-from-your-server",
      countryCode: "US",
      elementSelector: "#payment-form",
      onStatus: (result) => console.log("Final status:", result.status),
    });
    await transaction.start({ paymentMethod: { type: "CARD" } });
  }

  if (window.SdkPayments) {
    startYuno();
  } else {
    window.addEventListener("sdk-payments-ready", startYuno);
  }
</script>

The form renders in #payment-form. Enter the test card 4507 9900 0000 0002, expiry 11/28, CVV 123, name John Doe, then click Pay. The result arrives in onStatus with the status SUCCEEDED.For iOS, Android, and every option, see the SDK Get started.

See the result

Check status and sub_status in the response. SUCCEEDED with APPROVED means the gateway approved the payment.
Open Payments in the dashboard, find your payment, and open it to see its details.
To receive the result on your server, configure a webhook and verify its signature (HMAC).

Payment statuses are listed in Payment statuses.

Pick your integration

Production uses the same objects and keys. Choose how much of the flow you own.

Yuno SDK

TutorialInstall the SDK on Web, iOS, or Android.

Build your own UI

GuideChoose the parameters and controllers for your own form.

Direct API

GuideOwn the whole flow from your backend.

Agents and MCP

GuideLet a coding agent call Yuno for you.

Troubleshooting

The API returns 401

The public-api-key or private-secret-key header is missing or wrong. Sandbox and production use different keys, so check that you copied the sandbox keys from the dashboard in Test Mode. See Authentication.

The payment ends in INTERNAL_ERROR

The workflow does not match your integration. Use DIRECT when your server sends the card, and SDK_SEAMLESS on the checkout session when the Web SDK creates the payment.

No provider processes the payment

Card has no published route. Open Routing and check that the Card route with the Yuno Test Payment Gateway is under the Published tab, and that Card is turned on in the Checkout builder.

The card is declined

Test cards are specific to a provider. The cards in this Quickstart only work when your sandbox routes Card to the Yuno Test Payment Gateway. Other results are listed on the Yuno Test Payment Gateway page.

Stuck on a term? See the Glossary. For URLs, keys, and specs see Developers.
